GaAs INTEGRATED CIRCUIT

μ PG2160T5K

L, S-BAND SINGLE CONTROL SPDT SWITCH

DESCRIPTION

The μ PG2160T5K is a GaAs MMIC for L, S-band SPDT (Single Pole Double Throw) switch which was developed

for mobile phone and other L, S-band applications.

This device can operate frequency from 0.5 to 3.0 GHz, with low insertion loss and high isolation.

This device is housed in a 6-pin plastic TSSON (Thin Shrink Small Out-line Non-leaded) package, and is suitable

for high-density surface mounting.

FEATURES

? Supply voltage

? Switch control voltage

: V DD = 2.4 to 2.8 V (2.6 V TYP.)

: V cont (H) = 2.4 to V DD (2.6 V TYP.)

: V cont (L) = ? 0.2 to 0.2 V (0 V TYP.)

Low insertion loss

High isolation

Handling power

: L ins 1 = 0.30 dB TYP. @ f = 0.5 to 1.0 GHz, V DD = 2.6 V, V cont (H) = 2.6 V, V cont (L) = 0 V

: L ins 2 = 0.35 dB TYP. @ f = 1.0 to 2.0 GHz, V DD = 2.6 V, V cont (H) = 2.6 V, V cont (L) = 0 V

: L ins 3 = 0.40 dB TYP. @ f = 2.0 to 2.5 GHz, V DD = 2.6 V, V cont (H) = 2.6 V, V cont (L) = 0 V

: L ins 4 = 0.50 dB TYP. @ f = 2.5 to 3.0 GHz, V DD = 2.6 V, V cont (H) = 2.6 V, V cont (L) = 0 V

: ISL1 = 25 dB TYP. @ f = 0.5 to 1.0 GHz, V DD = 2.6 V, V cont (H) = 2.6 V, V cont (L) = 0 V

: ISL2 = 18 dB TYP. @ f = 1.0 to 2.0 GHz, V DD = 2.6 V, V cont (H) = 2.6 V, V cont (L) = 0 V

: ISL3 = 17 dB TYP. @ f = 2.0 to 2.5 GHz, V DD = 2.6 V, V cont (H) = 2.6 V, V cont (L) = 0 V

: ISL4 = 13 dB TYP. @ f = 2.5 to 3.0 GHz, V DD = 2.6 V, V cont (H) = 2.6 V, V cont (L) = 0 V

: P in (0.1 dB) = +21.0 dBm TYP. @ f = 2.0/2.5 GHz, V DD = 2.6 V, V cont (H) = 2.6 V, V cont (L) = 0 V

High-density surface mounting : 6-pin plastic TSSON package (1.0 × 1.0 × 0.37 mm)

APPLICATIONS

? L, S-band digital cellular or cordless telephone

? W-LAN, WLL and Bluetooth

ORDERING INFORMATION

etc.

Part Number

μ PG2160T5K-E2

Order Number

μ PG2160T5K-E2-A

Package

6-pin plastic TSSON

Note

(Pb-Free)

Marking

Supplying Form

? Embossed tape 8 mm wide

? Pin 1, 6 face the perforation side of the tape

? Qty 5 kpcs/reel

Note With regards to terminal solder (the solder contains lead) plated products (conventionally plated), contact

your nearby sales office.

Remark To order evaluation samples, contact your nearby sales office.

Part number for sample order: μ PG2160T5K-A

Caution Observe precautions when handling because these devices are sensitive to electrostatic discharge.

Document No. PG10635EJ01V0DS (1st edition)

Date Published September 2006 NS CP(K)

2006
